We have designed automation solutions in view of easy installation, long life and low maintenance, both for private and industry sectors for various applications,

featuring automatic products designed to meet all needs.

AWININGS-SHUTTERS

GATES

ACCESSORIES
SOLE
Control unit for tubular motors with mechanical limit switch, on board integrated receiver, able to manage both blinds and shutters, the possibility to connect also anemometer both radio and wire, rain sensor.

DOWNLOAD DATA SHEET

DOWNLOAD INSTRUCTION
OMBRA
Control unit for tubular motors with mechanical limit switch, on board integrated receiver, able to manage both blinds and shutters.

DOWNLOAD DATA SHEET

DOWNLOAD INSTRUCTION
VENTO
The VENTO sensor is a wind and sun detection device, with an integrated control unit that sends a radio transmission (433 MHz) in the event of any wind or sun alarm. Individual or centralized control for motors for shutter motors, curtains or similar.

DOWNLOAD DATA SHEET

DOWNLOAD INSTRUCTION
DOMO
Control unit for one or two tubular motors with mechanical limit switch, with integrated receiver for curtains with the possibility to connect also anemometer both radio and wire, rain sensor (only in the two-motor DOMO2 version).

DOWNLOAD DATA SHEET

DOWNLOAD INSTRUCTION

DUETTO
Control unit for two mechanical limit switch motors, mounted on the same shaft roller, with integrated receiver, able to manage both blinds and shutters and the possibility to connect also anemometer both radio and wire and rain sensor. Ideal for PERGOLA installations.

DOWNLOAD DATA SHEET

DOWNLOAD INSTRUCTION

TUBO
Control unit for tubular motors mechanical limit switch, with integrated receiver, able to manage: blinds, shutters, blinds, screens the possibility of connecting all the climate sensors via radio. Fitted for all tubes of tubular motors (inside installation).

DOWNLOAD DATA SHEET

DOWNLOAD INSTRUCTION

VIBRA
433 Mhz radio vibration sensor for awnings. The sensor offers a reading of vertical and lateral oscillations. The safety battery system offers greater performance in terms of battery longevity. It can be placed on a curtain bar or in any case of a movement system where a wind alarm reading is required.

DOWNLOAD DATA SHEET

DOWNLOAD INSTRUCTION
PIOGGIA
The rain sensor is a capacitive sensor, this means that it detects the change of state in the sensitive surface. This sensor is therefore able to transmit information to the control panel every time it changes its status, as in the case of rain. Indicated as an alarm beacon for awnings, vasistas, shutters, irrigation systems or proximity control (eg: touch button).

DOWNLOAD DATA SHEET

DOWNLOAD INSTRUCTION

IDT
It allows the command and the centralization of several motors. In addition to the local command, each motor can be controlled by the general command in sequence or in parallel by means of low-voltage signals of a bus line.

DOWNLOAD DATA SHEET

DOWNLOAD INSTRUCTION

MOD
It allows the grouping of 2 or 4 motors with the possibility of single and general drive.

DOWNLOAD DATA SHEET

DOWNLOAD INSTRUCTION

TELO
This line of transmitters has a minimal design. The 10-channel version that can be programmed from 1 to 10 plus the general channel is available too. This transmitter has a very simple use because it is equipped with a raise button, stop and descent. In addition there is an additional button that allows you to select the shutter or curtain to be moved.

DOWNLOAD DATA SHEET

DOWNLOAD INSTRUCTION

RADE
This line of transmitters has an elegant design available in a 16-channel version with TIMER. Equipped with a raise button, stop and descent and selection of the channel that allows you to select the shutter or curtain to be moved.

DOWNLOAD DATA SHEET

DOWNLOAD INSTRUCTION

PORTA
Electronic control unit for rolling shutters, with built-in radio receiver. Motor output up to 1500 W. There are 4 selectable inputs to connect safety devices, limit switches, emergency lock or control buttons for opening and closing function.

DOWNLOAD DATA SHEET

DOWNLOAD INSTRUCTION
PORTA SB
Electronic control unit for rolling shutters, with built-in radio receiver. Motor output up to 1500 W. There are 4 selectable inputs to connect safety devices, limit switches, emergency lock or control buttons for opening and closing function. Battery pack included for emergency electrobrake release by transmitter.

DOWNLOAD DATA SHEET

DOWNLOAD INSTRUCTION
COMANDO
Electronic control unit for the automation of sliding gates and overhead doors with built in radio receiver. It is equipped with initial motor boost and motor power adjustment, obstacle detection with adjustable sensitivity, programmable deceleration and many other functions.

DOWNLOAD DATA SHEET

DOWNLOAD INSTRUCTION
COMANDO24
Low voltage 24Vdc control unit for the automation of sliding gates and barriers with built in radio receiver. It is equipped with initial motor boost and motor power adjustment, obstacle detection with adjustable sensitivity, programmable deceleration power, output for safety devices ,and many other functions.

DOWNLOAD DATA SHEET

DOWNLOAD INSTRUCTION
ANTA
Electronic control unit for the automation of swinging gates, with built-in radio receiver. Initial motor boost, motor power adjustment, deceleration, adjustable deceleration power function, two limit switches for each motor. It is possible to manage control buttons for different ways of working. Several functions available.

DOWNLOAD DATA SHEET

DOWNLOAD INSTRUCTION
ANTA24
Low voltage control panel for automation of swinging gates, with built-in radio receiver. Equipped with safety transformer. Possibility to connect a battery or a photovoltaic panel. Available in 24Vdc model. Some functions as obstacle detection, motor speed and motor power adjustment, selectable inputs functions, deceleration power selection already configured.

DOWNLOAD DATA SHEET

DOWNLOAD INSTRUCTION
FOTO
Wall-mounted encoding photocells, range of up to 25 m. Supply 12-24vdc.

DOWNLOAD DATA SHEET

DOWNLOAD INSTRUCTION
FOTO IN
Embed modulated IR coded photocells. Nominal range of 25 m Max. Supply 12-24vdc.

DOWNLOAD DATA SHEET

DOWNLOAD INSTRUCTION
FOTO 180
Modulated IR outdoor coded photocells, 180° rotation and nominal range of 20 m. Supply 12-24vdc.

DOWNLOAD DATA SHEET

DOWNLOAD INSTRUCTION
FOTO BAT
Modulated IR outdoor coded photocells, with transmitter battery operated, 180° rotation and nominal range of 20 m. Supply 12-24vdc.

DOWNLOAD DATA SHEET

DOWNLOAD INSTRUCTION

RECEIVER IN
Two channels receiver, compatible common transmitters. Monostable working mode. Indoor installation.

DOWNLOAD DATA SHEET

DOWNLOAD INSTRUCTION

RECEIVER OUT
Two channels receiver, compatible common transmitters. Monostable working mode. Outdoor installation.

DOWNLOAD DATA SHEET

DOWNLOAD INSTRUCTION

RECEIVER TEMPO
Two channel receiver. NC and NO contacts. Different selectable functions for each channel: monostable, bistable, 3sec. or 6sec. temporized, step by step and momentary.

DOWNLOAD DATA SHEET

DOWNLOAD INSTRUCTION

PROXY READER
Proximity readers, indoor solution. Functions: proximity read/write and card reading.

DOWNLOAD DATA SHEET

DOWNLOAD INSTRUCTION

LOOP
Dual channel loop detectors are used to identify the presence of vehicles by means of two independent inductive loops buried under the road and can be used in almost any application.

DOWNLOAD DATA SHEET

DOWNLOAD INSTRUCTION

EDGE RADIO
The system is made up of transmitter device that is connected to the safety edge and receiver equipment that is connected to the door’s control panel. Communications are established by 433MHz two-way radio between the transmitter and the receiver.

DOWNLOAD DATA SHEET

DOWNLOAD INSTRUCTION
LUCE 01
Universal flashing lamp with flashing LED board or BULB (24-230V) lamp without flashing board. Gates installation.

DOWNLOAD DATA SHEET

DOWNLOAD INSTRUCTION
LUCE 02
Universal flashing lamp with LED lamp and flashing board. Garage doors installation.

DOWNLOAD DATA SHEET

DOWNLOAD INSTRUCTION
LUCE 03
Universal flashing lamp with LED lamp and flashing board. Garage doors installation.

DOWNLOAD DATA SHEET

DOWNLOAD INSTRUCTION
LUCE 03 WIRELESS
Universal flashing lamp with LED lamp and flashing board. Garage doors installation. Battery supplied, no wire connection, on door installation with movement detection.

DOWNLOAD DATA SHEET

DOWNLOAD INSTRUCTION

MANO
Transmitter 3 channel 433.92 MHz rolling code, self-learning and built-in proximity receiver, multi fix code copier.

DOWNLOAD DATA SHEET

DOWNLOAD INSTRUCTION
DITO
Transmitter 4 channel 433.92 MHz rolling code,

DOWNLOAD DATA SHEET

DOWNLOAD INSTRUCTION

DIGIT
Digital switch with 12 keys and 2 channels to be used in conjunction with the receiver.

DOWNLOAD DATA SHEET

DOWNLOAD INSTRUCTION
